M16878/4-BMG-2

SKU WM878/04-10E37-2

M16878/4-BMG-2 is a 10 AWG Silver plated copper conductor general purpose electronic hook-up wire with a single layer of polytetrafluoroethylene (PTFE) insulation. This wire is resistant to thermal aging, solder iron damage, open flames, moisture, solvents, grease, ozone and other chemicals. Commonly used in high temperature internal electronic applications, these wires have low power loss and are ideal for applications requiring high frequency. This specification is currently referred to as NEMA HP3 Type E

VORRÄTIG

111 M

Hersteller Vorlaufzeit 91 Tage

Volumen-Preise

1	6,85 € / M
76	6,55 € / M
152	6,27 € / M
305	6,01 € / M
762	5,78 € / M

Standort Lager

Arizona	0.01 10 KM	0.1 KM	341.21 FT	1.04 100 M	0.34 1000 FT	3.41 100 FT	104 M
Gelnhausen	0 10 KM	0 KM	0 FT	0 100 M	0 1000 FT	0 100 FT	0 M
Mexicali	0 10 KM	0 KM	0 FT	0 100 M	0 1000 FT	0 100 FT	0 M
Queretaro	0 10 KM	0 KM	0 FT	0 100 M	0 1000 FT	0 100 FT	0 M
Tennessee	0 10 KM	0 KM	0 FT	0 100 M	0 1000 FT	0 100 FT	0 M
Texas	0 10 KM	0.01 KM	22.97 FT	0.07 100 M	0.02 1000 FT	0.23 100 FT	7 M

Haftungsausschluss

Die Abbildungen dienen als allgemeine Referenz und stellen möglicherweise nicht die tatsächliche Teilenummer dar. Nicht alle Produkte sind für jedes Land oder jeden Kunden verfügbar. Der Lagerbestand wird täglich aktualisiert. Für Lagerbestände gilt: Zwischenverkauf vorbehalten.

Spezifikationen

Item Extra Description	M16878/4-BMG-2 \| NEMA HP3 Type E
Item Description	M16878/4-BMG-2 is a 10 AWG Silver plated copper conductor general purpose electronic hook-up wire with a single layer of polytetrafluoroethylene (PTFE) insulation. This wire is resistant to thermal aging, solder iron damage, open flames, moisture, solvent
Price Unit	MFT
Hersteller	Alpha Wire, Harbour Industries, Helistrand, Specialty Cable Corporation, Super-Temp Wire & Cable, Quirk, Astro Industries, QPL Sources
Lead Time (Days)	91
Manufacturer Part Number	878/04-10E37-2
Stranding	37
Stärke	10
Farbcode	Red
Steckverbinder Typ	Silver Plated Copper
Isolierung	Extruded PTFE
Temp	200

Produktübersicht

M16878 high performance wires meet requirements for small dimensions, high temperature resistance, low weight and low flame propagation. Typical uses for the M16878 wire include harness applications for the military or aerospace industries, and internal wiring of electronic equipment.

Dokumente / Datenblätter

Alternative Teilenummern

HP3-E-BMG-2
